Implant Bar Design Service
Product brief. Implant Bar Design is our overdenture service: from verified implant-level scans, we design the complete bar — Dolder, Hader or round profile — with attachments, spacers and passive-fit verification built in, delivered mill- or cast-ready within 12–24 hours.
A bar is a precision mechanism, not a bent piece of metal: retentive profile height matched to the matrix system, interp implant parallelism managed or compensated, cantilever length kept within biomechanical limits, and hygiene access left where the patient’s brush can actually reach. Our designers balance all four against your chosen attachment system — Locator, clip matrices, or ball-and-socket — and document the decisions on the case sheet.
What is included in every case
- Dolder bars — with or without occlusal wings, retentive profile matched to your clip matrix
- Hader bars — with vinyl clip design for hinged retention characteristics
- Round / egg-shaped bars — for ball-type and various matrix attachments
- Milled titanium or printed casting patterns — per your fabrication route
- Spacer and housing planning — correct clearance for the overdenture processing and pick-up
- Cantilever and hygiene documentation — lengths and interspaces noted on the case sheet
What we need from you
- Verified implant-level scan (open tray) with scan bodies in place, and bite registration
- Implant system and number of implants; abutment height if multi-unit
- Bar profile and attachment system — Dolder/Hader/round plus the matrix brand you process with
Turnaround
Standard implant bar design is returned within 12–24 hours of case receipt. Urgent case? Send it through with your deadline and we will confirm the schedule before starting.
Why labs outsource implant bar design to Odontalab
- Attachment-aware design — the bar is built around your matrix system, not the other way round
- Free unlimited minor revisions until the design is approved
- Library-verified interfaces and documented cantilever limits on every case
- One design partner for bars, overdenture setups and full-arch bridges — fewer vendors to manage
Which bar profiles do you design?
Can you design for Locator or clip attachments?
How fast can a case be returned?
Have an overdenture bar to outsource?
Send the verified scan and attachment system — we will confirm the design path and delivery time within one working day.
